Karan Acoustics Master Collection PHONOa Phono Preamplifier

$63,500.00

FEATURES:

.

LISTEN TO BELIEVE – We invite everyone to visit our shop! We strongly believe in personal experience, trying something out yourself than to take online reviews and word for it.
.
Categories: , , ,

Description

SPECIFICATIONS:
PHONO INPUTS 6 (3 x Single-Ended RCA + 3 x Balanced XLR)
LINE OUTPUTS 2 (1 x Single-Ended RCA + 1 x Balanced XLR)
PHONO EQ SETTINGS
RIAA
 +/- 0.1 dB
EMI
 +/- 0.15 dB
DECCA
 +/- 0.15 dB
COLUMBIA
 +/- 0.15 dB
TELDEC
 +/- 0.1 dB
OUTPUT IMPEDANCE 90 Ohm
OUTPUT LEVEL 1.55 V/RMS (nominal)
18.0 V/RMS (maximum / balanced / 600 Ohm load)
GAIN from 48 to 71 dB (multiple internal adjustments available, please see user manual)
FREQUENCY RESPONSE 20 Hz to 20 kHz, +/- 0 dB; (1.5 Hz to 1 MHz, -3 dB)
DISTORTION THD 0.003% (Full output, 20 Hz to 20 kHz)
IMD 0.003% (Full output)
SPEED Rise and Settling time < 450 ns
Slew rate 1.500 V/us (Amplification stages)
SIGNAL TO NOISE RATIO > 90 dB (Phono MM), > 81 dB (Phono MC)
AC VOLTAGE 115 V or 230 V (nominal line voltage)
AC VOLTAGE RANGE +/- 10% (from nominal line voltage)
POWER CONSUMPTION 60 W (maximum)
WARRANTY 5 years, parts and labor
NET DIMENSIONS (w/h/d) 504 x 141 x 390 mm; 19.8 x 5.6 x 15.3 inch / – Main control unit and Power supply unit
NET WEIGHT Main control unit: 15.0 kg / 32.8 lbs; Power supply unit: 17.1 kg / 37.5 lbs

.

DEVELOPED AND MANUFACTURED IN:

Serbia

.
