Description
SPECIFICATIONS:
SINGLE LOUDSPEAKER PERFORMANCE
Frequency Response (-3 dB) (1) 95 – 16,000 Hz
Frequency Range (-10 dB) (1) 83 – 19,000 Hz
Nominal Coverage Angle (H × V) (1 – 4 kHz) 145° × 140°
Nominal Coverage (H x V) (1 – 10 kHz) 130° × 130°
AES transducer test (5) Bose extended-lifecycle test (4)
Power Handling, Long-term Continuous 20 W 16 W
Power Handling, Peak 80 W 64 W
Sensitivity SPL/1W @ 1 m (2) 87 dB 87 dB
Calculated Maximum SPL @ 1 m (3) 100 dB 99 dB
Calculated Maximum SPL @ 1 m, Peak 106 dB 105 dB
Loudspeaker EQ
No Bose EQ required when speaker used for general use. Bose EQ Voicing and SmartBass available. EN54-24 Equalization is required for EN54-24 use; refer to FS2SE EN54-24 Certified ratings
document on pro.bose.com for details
Recommended High-Pass Protection 85 Hz with minimum 24-dB/octave filter
Transformer taps 70V: 1, 2, 4, 8, 16 W, bypass
100V: 2, 4, 8, 16 W, bypass
TRANSDUCERS
Full-Range Driver 1 × 2.25-inch woofer (57 mm)
Nominal Impedance 16 ohms (transformer bypass)
—
FreeSpace IZA 190-HZ integrated zone amplifier
Amplifier Power
1 x 90W @ 70/100V
Frequency Response
60 Hz – 20 kHz (+0/-3 dB, @ 1 W reference 1 kHz)
THD+N
≤1 % (at full rated power)
Dynamic Range
88 dB
Built-in Loudspeaker EQ
Bose FreeSpace FS2 or FS4, HPF only
Input Channels
Mic/Line Inputs: 1 Balanced mic/line
Line Inputs: 2 Unbalanced line
Page Inputs: 1 Balanced mic
Auxiliary Input: 1 Unbalanced line
.
DEVELOPED AND MANUFACTURED IN:
United States
.
WARRANTY:
5 years
.
